Control cable

Control Cables, generally, multi-Conductor Cables, one of the giants of the cable industry, are often used in industrial development and household electricity. These Flexible Cables are Low Voltage PVC XLPE insulation control cables, Instrument Cables, Galvanized Steel Wire Armored Control Cable, Flexible Cable, Control Cable with Screen/Shield, 0.6/1kV Paired or Triplex Instrument Cables, 0.6/1kV Paired or Triplex Armored Instrument Cable, etc.

About Hongtai Cable Control Cable Products

SY PVC /PVC/GSWB/PVC Control Cable

Conductor Material: Annealed Copper Wire according to BS6360 / VDE0295 Class 5.

Insulation Shield: PVC

Shielding material: Tinned steel woven wire mesh (GSWB)

Sheath material: PVC (Type TM2 to BS7655)

Rated voltage: 300/500V

Operating temperature range: Coiled: -15°C to +70°C Fixed: -35°C to +70°C

Minimum bending radius: 6 times the maximum outside diameter of the cable

The field of application covers electrical systems installed in dry or humid rooms,

especially in industrial use. They are suitable for use as measuring, monitoring and

control cables in machine tool construction, plant installation work, Power Stations,

heating and air conditioning systems, refrigeration equipment, office automation

equipment, and data processing systems. The tightly woven steel wire mesh provides

effective physical protection for the cable. *Note: This cable should not be installed in

areas where continuous curves are required.

Reference Standard: VDE specification BS6500 and VDE0250

PVC Insulated Flat Cable

Conductor material: flexible class 5 Copper Conductor

Insulation Material: polyvinyl chloride

Sheath material: polyvinyl chloride

Sheath color: black

Rated voltage: 300/500V

Rated temperature: -5 to +70°C

Minimum bending radius: 10 times the thickness of the cable

Core identification: Black core with white numbers Conductor green/yellow each.

Maximum lifting height: 80m

Maximum speed: 10m/s

The cables are used in transportation for lifting equipment and as Power Supply Cables

in building transportation systems to move mechanical components. These cables are

highly flexible and can be subjected to large and frequent bends.

Reference Standard: VDE specification BS6977, IEC227 Part 6 and CENELEC HD 359 S2

H05VVF Control Cable

300/500V control cable with super Flexible Copper conductor, thermoplastic PVC Insulation,

and thermoplastic PVC Sheath.

Conductor: Specialized ultra-Flexible Copper Conductor.

Insulation: flexible 70°C thermoplastic PVC

Core construction: 2, 3, or 4 Conductors articulated together

Sheath: Thermoplastic PVC

H05VVF is mostly used as a connecting cable in machine tools and electrical equipment.

Its extreme Flexibility at low temperatures allows it to be used in portable equipment in

both indoor and outdoor environments.

Model: 2-core 3182Y.1 control cable, 2-core 3182Y.2, 3182Y.3, 3182Y.4, 3-core 3183Y.1 control

cable, 4-core 3184Y.1

Reference Standard: The cable is British Standard, subject to quotation.

CVV 2-30 Cores Control Cable

Conductor: Multi-strand conductor

Insulation: Black PVC

Marking: Black insulator with white numbers printed on it

Filling: Reasonable filling

Winding: Reasonable

Sheath: Black PVC

Application: Electrical equipment, control circuits in power stations, outdoors, and

distribution equipment, etc.

This control cable can be produced according to GB9330-1988, IEC, DIN, and BS

standards, and the factory can also produce cables according to other standards.

The control cable is suitable for the wiring of electrical controlling equipment and

instruments, monitoring and controlling return circuits, electrical protection, and

measurement in the power distribution units under the circumstance that the rated

voltage is up to 450/750V AC.

Model: CVV, CVV-S, CVV-SWA

Control Cable A03VV-F

Insulation: PVC

Light sheath: PVC Flexible Control Cable.

Rated voltage: 300/300 V

Rated temperature: 60 °C

Maximum tension: 50 N/mm2

Minimum bending radius: 4 times the outer diameter of the cable

Conductor: Non-tinned, annealed copper Flexible Conductor

Insulation: PVC of TI2 quality

Sheath: PVC of TM2 quality

Color code: 2-core brown, blue; 3-core black, brown, blue; 4-core black, black,

brown, blue.

Italian Standard: CEI 20-20/5

International Standard: CENELEC HD 21.5 Sez. 3

Model: A03VVF, A05VVF, FROR, N07V-K
